Flansche
Flanges

Losflansch für Vorschweißbund DIN Backing flange for adapters DIN
mit Stahleinlage with steel insert
10/16 = Bohrbild PN10 / Druck PN16 10/16 = Flange standard PN10 / p16
d Material PN VE Art. Nr.
material Pack
7 d20 PP-GFK 10/16 1 70217
7 d25 PP-GFK 10/16 1 70218
Fittings PVC-U
7 d32 PP-GFK 10/16 1 70219
7 d40 PP-GFK 10/16 1 70220
7 d50 PP-GFK 10/16 1 70221
7 d63 PP-GFK 10/16 1 70222
7 d75 PP-GFK 10/16 1 70223
7 d90 PP-GFK 10/16 1 70224
7 d110 PP-GFK 10/16 1 70225
7 d125 PP-GFK 10/16 1 70226
7 d140 PP-GFK 10/16 1 70227
7 d160 PP-GFK 10/16 1 70228
7 d180 PP-GFK 10/16 1 70229
7 d200 PP-GFK 10 1 70230
7 d225 PP-GFK 10 1 70231
7 d250 PP-GFK 10 1 70232
7 d280 PP-GFK 10 1 70233
7 d315 PP-GFK 10 1 70234

Festflansch DIN-ANSI-JIS Fix flange DIN-ANSI-JIS
Klebe solvent socket
- gedreht - - turned -
DIN-ANSI-JIS DIN-ANSI-JIS
d Material DN VE Art. Nr.
material Pack
1 d20 PVC-C PN16 - class 150 - 10K 1 142260
1 d25 PVC-C PN16 - class 150 - 10K 1 142261
1 d32 PVC-C PN16 - class 150 - 10K 1 142262
1 d40 PVC-C PN16 - class 150 - 10K 1 142263
1 d50 PVC-C PN16 - class 150 - 10K 1 142264
1 d63 PVC-C PN16 - class 150 - 10K 1 142265

Festflansch DIN-ANSI-JIS Fix flange DIN-ANSI-JIS
Klebe clue
- gedreht - - turned -
DIN-ANSI-JIS DIN-ANSI-JIS
d Material DN VE Art. Nr.
material Pack
1 d20 PVC PN16 - class 150 - 10K 1 142069
1 d25 PVC PN16 - class 150 - 10K 1 142070
1 d32 PVC PN16 - class 150 - 10K 1 142071
1 d40 PVC PN16 - class 150 - 10K 1 142072
1 d50 PVC PN16 - class 150 - 10K 1 142073
1 d63 PVC PN16 - class 150 - 10K 1 142074
1 d75 PVC PN16 - class 150 - 10K 1 142075
1 d90 PVC PN16 - class 150 - 10K 1 142076
1 d110 PVC PN16 - class 150 - 10K 1 142077

164
