2-Wege modularer Industriekugelhahn M1 mit
Pneumatikantrieb standard, silikonfrei
2-way modular industrial ball valve M1 with pneuamtic Valves PVC-U
actuator standard, silicone free

Kugelhahn 2W M1 metrisch Ball Valve 2W M1 metric
PVCu Klebemuffe PVCu solvent socket ends
Sitzdichtung: PTFE seat-sealing: PTFE
PO-NC PO-NC
d DN Typ PN VE EPDM FPM
Pack Conbest
1 16 10 UT05-2 16 1 124028A 124035
1 20 15 UT05-2 16 1 124029A 124036
1 25 20 UT05-2 16 1 124030A 124037
1 32 25 UT05-2 16 1 124031A 124038
1 40 32 UT15-4 16 1 124032A 124039
1 50 40 UT15-4 16 1 124033A 124040
1 63 50 UT17-4 16 1 124034A 124041
1 75 65 UT30-4 16 1 124257 124260
1 90 80 UT35-4 16 1 124258 124261
1 110 80 UT35-4 16 1 124259 124262

Kugelhahn 2W M1 metrisch Ball Valve 2W M1 metric
PVCu Klebemuffe PVCu solvent socket ends
Sitzdichtung: PTFE seat-sealing: PTFE
PO-NO PO-NO
d DN Typ PN VE EPDM FPM
Pack
1 16 10 UT05-2 16 1 124042A 124049
1 20 15 UT05-2 16 1 124043A 124050
1 25 20 UT05-2 16 1 124044A 124051
1 32 25 UT05-2 16 1 124045A 124052
1 40 32 UT15-4 16 1 124046A 124053
1 50 40 UT15-4 16 1 124047A 124054
1 63 50 UT17-4 16 1 124048A 124055
1 75 65 UT30-4 16 1 124268 124271
1 90 80 UT35-4 16 1 124269 124272
1 110 80 UT35-4 16 1 124270 124273

Kugelhahn 2W M1 metrisch Ball Valve 2W M1 metric
PVCu Klebemuffe PVCu solvent socket ends
Sitzdichtung: PTFE seat-sealing: PTFE
PO-DA PO-DA
d DN Typ PN VE EPDM FPM
Pack
1 16 10 UT05DA 16 1 124056A 124063
1 20 15 UT05DA 16 1 124057A 124064
1 25 20 UT05DA 16 1 124058A 124065
1 32 25 UT05DA 16 1 124059A 124066
1 40 32 UT15DA 16 1 124060A 124067
1 50 40 UT15DA 16 1 124061A 124068
1 63 50 UT15DA 16 1 124062A 124069
1 75 65 UT20DA 16 1 124274 124277
1 90 80 UT20DA 16 1 124275 124278
1 110 80 UT20DA 16 1 124276 124279

55
