2-Wege modularer Industriekugelhahn M1 elektrisch mit
Posi, silikonfrei
2-way modular industrial ball valve M1 with electric actuator Valves PVC-U
with position feedback, silicone free

Kugelhahn 2W M1 NPT Ball Valve 2W M1 NPT
Gewindemuffe R female thread socket ends R
Sitzdichtung: PTFE seat-sealing: PTFE
EO EO
posi posi
d DN Typ Spannung PN VE EPDM FPM Conbest
Voltage Pack
5 3/8" 10 ER20 15-30VAC 16 1 510558 510572
5 1/2" 15 ER20 15-30VAC 16 1 510559 510573
5 3/4" 20 ER20 15-30VAC 16 1 510560 510574
5 1" 25 ER20 15-30VAC 16 1 510561 510575
5 1 1/4" 32 ER20 15-30VAC 16 1 510562 510576
5 1 1/2" 40 ER20 15-30VAC 16 1 510563 510577
5 2" 50 ER20 15-30VAC 16 1 510564 510578

Kugelhahn 2W M1 NPT Ball Valve 2W M1 NPT
Gewindemuffe R female thread socket ends R
Sitzdichtung: PTFE seat-sealing: PTFE
EO EO
posi posi
d DN Typ Spannung PN VE EPDM FPM
Voltage Pack
5 3/8" 10 ER20 90-240VAC 16 1 510565 510579
5 1/2" 15 ER20 90-240VAC 16 1 510566 510580
5 3/4" 20 ER20 90-240VAC 16 1 510567 510581
5 1" 25 ER20 90-240VAC 16 1 510568 510582
5 1 1/4" 32 ER20 90-240VAC 16 1 510569 510583
5 1 1/2" 40 ER20 90-240VAC 16 1 510570 510584
5 2" 50 ER20 90-240VAC 16 1 510571 510585

Kugelhahn 2W M1 metrisch Ball Valve 2W M1 metric
PE Schweißmuffe PE fusion socket ends
Sitzdichtung: PTFE seat-sealing: PTFE
EO EO
posi posi
d DN Typ Spannung PN VE EPDM FPM
Voltage Pack
5 16 10 ER20 15-30VAC 16 1 510634 510648
5 20 15 ER20 15-30VAC 16 1 510635 510649
5 25 20 ER20 15-30VAC 16 1 510636 510650
5 32 25 ER20 15-30VAC 16 1 510637 510651
5 40 32 ER20 15-30VAC 16 1 510638 510652
5 50 40 ER20 15-30VAC 16 1 510639 510653
5 63 50 ER20 15-30VAC 16 1 510640 510654

Kugelhahn 2W M1 metrisch Ball Valve 2W M1 metric
PE Schweißmuffe PE fusion socket ends
Sitzdichtung: PTFE seat-sealing: PTFE
EO EO
posi posi
d DN Typ Spannung PN VE EPDM FPM
Voltage Pack
5 16 10 ER20 90-240VAC 16 1 510641 510655
5 20 15 ER20 90-240VAC 16 1 510642 510656
5 25 20 ER20 90-240VAC 16 1 510643 510657
5 32 25 ER20 90-240VAC 16 1 510644 510658
5 40 32 ER20 90-240VAC 16 1 510645 510659
5 50 40 ER20 90-240VAC 16 1 510646 510660
5 63 50 ER20 90-240VAC 16 1 510647 510661
